חותך צנרת חשמלי

Features
Portable – At a weight of 32 lbs., compact size, integrated handle and cord wrap makes it convenient to carry and easy to store
High Efficiency – Quick-acting engagement feature and easy to use feed screw ensure high-speed cutting.
Quality Cuts – Optimal cutter wheel profile allows for an efficient cold cutting operation resulting in a smooth quality cut
Simple Control – Two rotating speeds for smooth cuts on long or short tubes. Foot bulb allows for hands free control of the power
Easy Maintenance – Save time on maintenance with the unique cutter wheel cartridge design that simplifies replacement without tools
Specifications
Nominal Pipe Capacity 1/2" to 4" (12mm to 100mm)
Actual Cutting Capacity 1/2" – 4.5" (12mm to 116mm)
Nominal Reaming Capacity 1/2" – 2" (16mm to 50mm) (optional accessory)
Maximum Tube Length 20' (6m)
Motor Type Universal
Motor Voltage 110V – 120V AC
Motor Current 5.8 Amp
Motor Frequency 50/60 Hz
Motor Power 705W
Roller Rotational Speed 225/385 RPM
Controls I-Low/0-Off/II-High and On/Off Foot Switch
Weight 32 lbs (14.5 kg)
Overall Dimensions 11.6" x 9.4" x 15.9" (295mm x239mm x 403mm)
Operating Temperature -4 to 122 degrees F (-20 to 50 degrees C)
MAXIMUM WALL THICKNESS

Copper 0.1" (2.5 mm) with E-855 Cutter Wheel (Catalog Number 66943)
Plastic 0.23" (5 mm) with E-855 Cutter Wheel (Catalog Number 66943)
Carbon Steel 0.1" (2.5 mm) with E-850 Cutter Wheel (Catalog Number 66938)
Stainless Steel 0.1" (2.5 mm) with E-850 Cutter Wheel (Catalog Number 66938)
Aluminum 0.1" (2.5 mm) with E-850 Cutter Wheel (Catalog Number 66938)
