DigiLevel Plus 60 cm – 081.251A

• The intelligent spirit level: the intelligent spirit level with vertical and horizontal angle display.
• Reference function for transferring angles
• Selectable units: ° degrees, %, mm/m
• Optimal use by AutoSound: The horizontal, vertical and 45° position is displayed together with an acoustic signal – helpful when aligning objects.
• FlipDisplay: the display automaticly turns when overhead measurements are involved. So the illuminated display is well readable under all conditions.
• Calibration function to recalibrate the sensor and increase the measuring accuracy
• Illuminated display
• Vertical and horizontal vial
• Milled measuring surfaces
• Strong magnets

Product code: 081.251A

Technical data

DIMENSIONS (W x H x D)	600 x 66 x 30 mm
WEIGHT with batteries	675 g
POWER SUPPLY	2 x 1,5V (type AAA/LR03)
ELECTRONIC SLOPE	± 0,1° at 0° … 1° ± 0,1° at 89°…90° ± 0,2° at 1° … 89°
DISPLAY ACCURACY	1 decimal place
VIAL PRECISION	± 1 mm/m
OPERATING TEMPERATURE	0 … 50 °C
STORAGE TEMPERATURE	-20 °C … 70 °C

Technology key

•  Auto sound
•  Magnetic
•  Soft Case
•  Uses 2 AAA batteries



Key Features

• Horizontal, vertical & 45° position displayed together with an acoustic signal
• Selectable units: ° degrees, %, mm/m
• Intelligent spirit level with vertical & horizontal angle display
• Reference function for transferring angles

Product features

Intelligent spirit level with vertical & horizontal angle display

The horizontal, vertical & 45° position is displayed together with an acoustic signal

AutoSound at 0°/45°/ 90°/135°/180°

Magnetic, with illuminated display
